Panels and

Cabling

This section discusses the MPA 152 rear panel features and cabling.

MPA 152 Rear Panel Features

The rear panel of the MPA 152 (shown in Figure 2 below) allows the user to connect power,

audio input, speakers, and remote control.

POWER

12V

0.6A MAX

OUTPUT

4/8

OHMS

CLASS 2 WIRING

DO NOT GROUND

OR SHORT

SPEAKER OUTPUTS!

INPUTS

REMOTE

VOL/MUTE

10V 50mA

MPA 152

1 2 3 654

Figure 2. MPA 152 Rear Panels Features

MPA 152 • Panels and Cabling 4
